The Gold Mountain Single Truss Arch Storage Shelter L20'xW30'xH12' is the perfect choice for anyone looking for a reliable and durable storage solution. This truss construction storage shelter is designed to be resistant towards water, UV, and fading, and can last up to 7-10 years under the right conditions. It features a freestanding style, mechanical doors at both ends, and a huge capacity for trucks, automobiles, and more bulk storage. This storage shelter will protect your belongings from wind, snow, and rain, and has a CSA/TUV Snow Rating Test Report and SGS fabric Certificate to guarantee its quality. Whether you need to store equipment, materials, or recreational items, the Gold Mountain Single Truss Arch Storage Shelter L20'xW30'xH12' is the perfect choice.
It’s necessary to tighten the roof fabric enough to avoid “hammocks” on the roof and also re-tighten once or twice again after a few months of use. This is important when assembly in cold weather (autumn and winter) because the fabric is stiff then and when we got the sun and warm weather afterward it will make the fabric “slack” again and need to be re-tighten before next winter.
Specifications:
Product Dimension
6.1m*9.15m*3.66m/20'*30'*12'
Floor Footprint
55.74m2/600ft2
Highest Height
3.66m/12’
Frame Material
Galvanized Steel
Cover Material
PVC/PE
Main Arch Tube Diameter
42mm/1.65''
Main Arch Tube Thickness
1.5mm/0.06''
Main Arch Space
1.83m/6'
Purlin Tube Diameter
40mm/1.57''
Purlin Tube Thickness
Door Size
4.3m*3.2m/14.1'*10.5'
Snow Rate Test Result:
203012R
Test Load
Deflection
Lb
Kpa
Point A (inch)
Point B (inch)
Point C (inch)
Step 1
0
Step 2
1005
1.52
1.4
1.6
1.2
Step 3
1507
2.28
2.2
2.3
Step 4
Keep the test load until 30 minutes
Step 5
Remove the test load
0.6
1.1
Step 6
The test sample can withstand the applied test load without damage.
